| 1 |
900-085 |
Bolt, Flange M6x16 (Zn)
|
CA$2.07
|
|
|
900-085 |
| 2 |
102-844 |
Handle Grip, Chute Rotation Crank
|
CA$5.49
|
|
|
102-844 |
| 3, 27 |
900-095 |
Flat Washer 20x10x2mm (Zn)
|
CA$2.25
|
|
|
900-095 |
| 4 |
102-829 |
Chute Rotation Rod (Upper)
|
CA$16.09
|
|
|
102-829 |
| 5 |
102-867 |
Cotter Pin
|
CA$3.33
|
|
|
102-867 |
| 6 |
102-928 |
Cardan Joint
|
CA$4.50
|
|
|
102-928 |
| 7 |
900-694 |
Spring Pin 4x18mm (BLK)
|
CA$3.33
|
|
|
900-694 |
| 8 |
102-901 |
Chute Rotation Rod (Lower)
|
CA$9.97
|
|
|
102-901 |
| 9 |
102-463 |
Coupler, Connecting Bar (Plastic)
|
CA$3.33
|
|
|
102-463 |
| 10 |
900-692 |
Nylon Insert Lock Nut, Hex M8 (Zn)
|
CA$2.41
|
|
|
900-692 |
| 11, 38 |
900-097 |
Flat Washer 16x8x1.5mm (Zn)
|
CA$1.99
|
|
|
900-097 |
| 12 |
102-929 |
Mounting Bracket, Worm Gear
|
CA$9.97
|
|
|
102-929 |
| 13 |
900-720 |
Spacer, Worm Gear
|
CA$3.33
|
|
|
900-720 |
| 14, 75 |
900-653 |
Carriage Bolt M8x18 (Zn)
|
CA$3.33
|
|
|
900-653 |
| 15 |
102-939 |
Cotter Pin 3.2x25mm
|
CA$3.33
|
|
|
102-939 |
| 16 |
102-927 |
Worm Gear
|
CA$15.37
|
|
|
102-927 |
| 17 |
103-151 |
Poly Skid Shoe
|
CA$13.88
|
|
|
103-151 |
| 18 |
102-935 |
28" Auger Housing (Light Grey)
|
CA$269.10
|
|
|
102-935 |
| 19 |
102-805 |
Spherical Bearing SB204
|
CA$4.24
|
|
|
102-805 |
| 20 |
102-839 |
Bearing Cap
|
CA$4.50
|
|
|
102-839 |
| 21 |
102-865 |
Bracket, Auger Belt
|
CA$4.50
|
|
|
102-865 |
| 22 |
102-811 |
Flat key 6x6x17mm
|
CA$3.33
|
|
|
102-811 |
| 23 |
900-681 |
Bolt, Hex M8x20 (Zn)
|
CA$3.48
|
|
|
900-681 |
| 24 |
900-669 |
Flat Washer 28x8x2mm (Zn)
|
CA$3.48
|
|
|
900-669 |
| 25 |
102-909 |
Driven Pulley, Auger Belt
|
CA$34.54
|
|
|
102-909 |
| 26 |
900-701 |
Extension Spring, Idler Pulley
|
CA$3.33
|
|
|
900-701 |
| 28 |
102-910 |
Idler Bracket, Auger
|
CA$13.17
|
|
|
102-910 |
| 29 |
900-703 |
Shoulder Bolt, Hex M10x13 (Zn)
|
CA$3.33
|
|
|
900-703 |
| 30 |
900-682 |
23mm-thread Bolt, Hex M8x45 (Zn)
|
CA$3.33
|
|
|
900-682 |
| 31 |
900-697 |
Spacer
|
CA$3.33
|
|
|
900-697 |
| 32 |
102-840 |
Idler Pulley, Auger Housing
|
CA$12.39
|
|
|
102-840 |
| 33 |
102-841 |
Bushing, Idler Pulley
|
CA$3.33
|
|
|
102-841 |
| 34 |
900-147 |
Nylon Insert Lock Nut, Hex M6 (Zn)
|
CA$2.18
|
|
|
900-147 |
| 35 |
900-276 |
Nylon Insert Lock Nut, Hex M10x1.5 (Zn)
|
CA$2.25
|
|
|
900-276 |
| 36, 37 |
103-849 |
Plastic Mounting Plate, Discharge Chute
|
CA$9.28
|
|
|
103-849 |
| 39 |
900-679 |
Bolt, Hex M6x20 (Zn)
|
CA$3.33
|
|
|
900-679 |
| 40 |
102-864 |
Ring Coupler, Chute Base (Plastic)
|
CA$3.33
|
|
|
102-864 |
| 41 |
102-906 |
Discharge Chute (light grey, 2022 version)
|
CA$48.45
|
|
|
102-906 |
| 42 |
900-657 |
Bolt, Phillips Pan Head M5x12 (Zn)
|
CA$2.07
|
|
|
900-657 |
| 43 |
900-748 |
Nylon Washer 16x7mm, Chute (BLK)
|
CA$3.33
|
|
|
900-748 |
| 44 |
900-691 |
Nylon Insert Lock Nut, Hex M5 (Zn)
|
CA$3.33
|
|
|
900-691 |
| 45 |
900-709 |
Extension Spring, Chute Deflector
|
CA$7.41
|
|
|
900-709 |
| 46 |
102-905 |
Chute Deflector (BLK, 2022 version)
|
CA$8.87
|
|
|
102-905 |
| 47 |
102-857 |
Shovel
|
CA$15.37
|
|
|
102-857 |
| 48 |
102-858 |
Shovel Holder
|
CA$7.41
|
|
|
102-858 |
| 49 |
900-677 |
Bolt, Hex M6x16 (Zn)
|
CA$3.33
|
|
|
900-677 |
| 50 |
900-700 |
Spring, Holding Bracket
|
CA$3.33
|
|
|
900-700 |
| 51 |
102-843 |
Guard, Discharge Chute
|
CA$7.41
|
|
|
102-843 |
| 52 |
900-655 |
Bolt, Phillips Flat Head M5x12 (Zn)
|
CA$3.33
|
|
|
900-655 |
| 53 |
102-945 |
Idler Pulley Assembly, Auger Housing
|
CA$18.89
|
|
|
102-945 |
| 54 |
102-218 |
Discharge Chute Assembly (2022 version)
|
CA$51.97
|
|
|
102-218 |
| 56 |
102-838 |
Impeller
|
CA$35.04
|
|
|
102-838 |
| 57 |
900-654 |
20mm-thread Carriage Bolt M8x25 (Zn)
|
CA$3.48
|
|
|
900-654 |
| 58 |
102-934 |
Worm Gear Pin
|
CA$9.97
|
|
|
102-934 |
| 59 |
102-933 |
Rubber Pad
|
CA$6.47
|
|
|
102-933 |
| 60 |
900-686 |
Bolt with washers, Hex M6x25 (Zn)
|
CA$3.33
|
|
|
900-686 |
| 61 |
102-832 |
0.24"x1.5" Shear Pin
|
CA$1.99
|
|
|
102-832 |
| 62 |
102-833 |
Boe-tie Cotter Pin 2mm
|
CA$1.99
|
|
|
102-833 |
| 63 |
102-794 |
27" Auger Shaft (HS7070E/HS7080E)
|
CA$33.36
|
|
|
102-794 |
| 64 |
102-938 |
Woodruff key 5x7.5x19mm
|
CA$3.33
|
|
|
102-938 |
| 65 |
102-796 |
Rh Auger (Right)
|
CA$37.43
|
|
|
102-796 |
| 66 |
102-866 |
Mounting Bracket, Chute Rocker Arm
|
CA$6.47
|
|
|
102-866 |
| 67 |
900-025 |
Nut, Serrated Flange M6 (Zn)
|
CA$1.99
|
|
|
900-025 |
| 68, 78 |
900-663 |
Flat Washer 38x19x1.5mm (Zn)
|
CA$3.48
|
|
|
900-663 |
| 69 |
102-849 |
Bearing Cap, Auger Shaft
|
CA$4.50
|
|
|
102-849 |
| 70 |
900-687 |
Bolt with flat washer, Hex M8x10 (Zn)
|
CA$3.33
|
|
|
900-687 |
| 71 |
102-845 |
Plastic Bushing, Auger Shaft
|
CA$5.49
|
|
|
102-845 |
| 72 |
102-795 |
Sleeve, Auger Shaft
|
CA$6.47
|
|
|
102-795 |
| 73 |
102-797 |
Rh Auger (Left)
|
CA$37.43
|
|
|
102-797 |
| 74 |
102-835 |
Bushing, Auger Shaft
|
CA$6.47
|
|
|
102-835 |
| 76 |
102-908 |
28" Scraper Blade (Grey)
|
CA$30.38
|
|
|
102-908 |
| 77 |
102-846 |
Plastic Bushing, Auger Shaft
|
CA$3.33
|
|
|
102-846 |
| 79 |
102-804 |
Bearing 6904Z
|
CA$10.79
|
|
|
102-804 |
| 80 |
900-704 |
O-Ring Spacer 25x20x1.2mm (Zn)
|
CA$3.33
|
|
|
900-704 |
| 81 |
102-803 |
Bearing 51104
|
CA$10.79
|
|
|
102-803 |
| 82 |
102-836 |
Oil Seal 32x20xH6mm
|
CA$3.48
|
|
|
102-836 |
| 83 |
103-161 |
Worm Shaft
|
CA$44.40
|
|
|
103-161 |
| 84 |
900-671 |
Spring Pin 6x35mm
|
CA$3.33
|
|
|
900-671 |
| 85 |
102-800 |
Bearing 16001Z
|
CA$10.79
|
|
|
102-800 |
| 86 |
102-853 |
Worm Gear Cover (Right)
|
CA$22.24
|
|
|
102-853 |
| 87 |
900-721 |
Wave Washer 15x10x0.3mm (BLK）
|
CA$3.33
|
|
|
900-721 |
| 88 |
900-695 |
Nipple Bolt M10x1
|
CA$7.41
|
|
|
900-695 |
| 89 |
102-855 |
Bushing 19mm, Auger Shaft
|
CA$3.33
|
|
|
102-855 |
| 90 |
102-834 |
Oil Seal 30x19xH7mm
|
CA$3.48
|
|
|
102-834 |
| 91 |
900-656 |
Bolt, Phillips Pan Head M5x10 (Zn)
|
CA$1.99
|
|
|
900-656 |
| 92 |
102-850 |
Helical Worm Gear
|
CA$48.45
|
|
|
102-850 |
| 93 |
102-852 |
Worm Gear Cover (Left)
|
CA$22.24
|
|
|
102-852 |
| 94 |
900-685 |
Bolt with washers, Hex M6x20 (Zn)
|
CA$3.33
|
|
|
900-685 |
| 96 |
102-877 |
50" Auger Cable
|
CA$21.58
|
|
|
102-877 |
| 97 |
102-949 |
Chute Rotation Rod Assembly
|
CA$48.89
|
|
|
102-949 |
| 98 |
102-860 |
U-Type Rod, Chute Deflector
|
CA$5.49
|
|
|
102-860 |
