| 1 |
101-338 |
Stator and Rotor Assembly
|
CA$164.06
|
|
|
101-338 |
| 2 |
104-622 |
Motor Stand
|
CA$29.59
|
|
|
104-622 |
| 3 |
101-359 |
Muffler Bracket
|
CA$7.54
|
|
|
101-359 |
| 4 |
104-619 |
Handle Connecting Bracket (Medal, blue)
|
CA$9.91
|
|
|
104-619 |
| 5 |
101-245 |
Detent Pin
|
CA$6.94
|
|
|
101-245 |
| 6 |
900-179 |
Hose Clamp 9mm
|
CA$2.44
|
|
|
900-179 |
| 8 |
104-624 |
Handle (blue)
|
CA$20.79
|
|
|
104-624 |
| 9 |
101-364 |
Anti Vibration Motor Mount (Big)
|
CA$7.33
|
|
|
101-364 |
| 10 |
900-059 |
Nut, Hex M8 (Zn)
|
CA$2.07
|
|
|
900-059 |
| 11 |
104-625 |
Fuel Tank
|
CA$48.33
|
|
|
104-625 |
| 12 |
102-372 |
Fuel Shutoff Valve
|
CA$7.74
|
|
|
102-372 |
| 13 |
900-067 |
Hose Clamp 7.5mm
|
CA$2.41
|
|
|
900-067 |
| 14 |
104-113 |
Fuel Cap
|
CA$10.60
|
|
|
104-113 |
| 15 |
900-033 |
Nut, Hex M5 (BLK)
|
CA$1.99
|
|
|
900-033 |
| 16 |
900-085 |
Bolt, Flange M6x16 (Zn)
|
CA$2.07
|
|
|
900-085 |
| 17 |
900-070 |
Rotor Bolt, Flange M10x225 (Zn)
|
CA$5.69
|
|
|
900-070 |
| 18 |
104-626 |
Gas Return Hose
|
CA$3.09
|
|
|
104-626 |
| 19 |
101-247 |
Cotter Pin
|
CA$2.78
|
|
|
101-247 |
| 20 |
900-069 |
Stator Bolt, Flange M6x140 (Zn)
|
CA$3.61
|
|
|
900-069 |
| 21 |
900-001 |
Bolt, Flange M6x12 (Zn)
|
CA$2.08
|
|
|
900-001 |
| 22 |
101-258 |
Crankcase Cover Guard
|
CA$6.53
|
|
|
101-258 |
| 23 |
900-062 |
Nut, Serrated Flange M10x1.25 (Zn)
|
CA$2.34
|
|
|
900-062 |
| 24 |
900-025 |
Nut, Serrated Flange M6 (Zn)
|
CA$1.99
|
|
|
900-025 |
| 25 |
900-081 |
Nut, Serrated Flange M8 (Zn)
|
CA$2.18
|
|
|
900-081 |
| 26 |
101-368 |
Exhaust Gasket
|
CA$2.42
|
|
|
101-368 |
| 27 |
101-369 |
Muffler
|
CA$41.93
|
|
|
101-369 |
| 28 |
900-063 |
Spring Washer 8mm (BLK)
|
CA$1.99
|
|
|
900-063 |
| 29 |
901-294 |
20mm-thread Bolt, Flange M6x50 (Zn)
|
CA$2.17
|
|
|
901-294 |
| 30 |
102-354 |
8" Wheel
|
CA$16.32
|
|
|
102-354 |
| 31 |
900-083 |
Bolt, Flange M8x16 (Zn)
|
CA$2.18
|
|
|
900-083 |
| 32 |
101-371 |
Wheel Axle
|
CA$5.46
|
|
|
101-371 |
| 33 |
900-017 |
Flat Washer 30x10x4mm (Zn)
|
CA$3.08
|
|
|
900-017 |
| 34 |
104-627 |
Control Panel Assembly (HG6250E)
|
CA$91.48
|
|
|
104-627 |
| 34.1 |
104-616 |
Control Panel Housing
|
CA$15.93
|
|
|
104-616 |
| 34.2 |
101-141 |
Ignition Switch
|
CA$9.99
|
|
|
101-141 |
| 34.3 |
101-854 |
Indicator Light
|
CA$5.90
|
|
|
101-854 |
| 34.4 |
101-239 |
Hour Meter
|
CA$26.85
|
|
|
101-239 |
| 34.5 |
101-394 |
Circuit Breaker (21A)
|
CA$38.77
|
|
|
101-394 |
| 34.6 |
101-395 |
Ground Terminal
|
CA$2.95
|
|
|
101-395 |
| 34.7 |
101-237 |
4-hole Receptacle 120/240V L14-30R
|
CA$15.68
|
|
|
101-237 |
| 34.8 |
101-236 |
Duplex Receptacle L5-20R
|
CA$7.44
|
|
|
101-236 |
| 34.9 |
101-396 |
Reset Button Switch 20A (L-Type)
|
CA$10.14
|
|
|
101-396 |
| 34.10 |
104-105 |
Receptacle Cover L14-30R (2023 version)
|
CA$5.37
|
|
|
104-105 |
| 34.11 |
104-106 |
Duplex Receptacle GFCI Cover (2023 version)
|
CA$5.72
|
|
|
104-106 |
| 34.12 |
101-857 |
Reset Button Switch Cover
|
CA$5.33
|
|
|
101-857 |
| 35 |
101-374 |
Ground Wire
|
CA$4.03
|
|
|
101-374 |
| 36 |
104-629 |
Voltage Regulator (5-6.5kw)
|
CA$25.26
|
|
|
104-629 |
| 37 |
900-012 |
Bolt, Flange M5x16 (Zn)
|
CA$2.03
|
|
|
900-012 |
| 38 |
900-057 |
Bolt, Flange M5x12 (Zn)
|
CA$2.07
|
|
|
900-057 |
| 39 |
102-175 |
Anti Vibration Motor Mount (Small)
|
CA$7.50
|
|
|
102-175 |
| 40 |
102-343 |
Handle Grip (Rubber)
|
CA$4.76
|
|
|
102-343 |
| 41 |
101-378 |
Motor Cover (rear)
|
CA$9.58
|
|
|
101-378 |
| 42 |
104-617 |
Stand (Blue)
|
CA$7.93
|
|
|
104-617 |
| 43 |
101-250 |
Anti Vibration Mount
|
CA$4.37
|
|
|
101-250 |
| 44 |
104-630 |
Side Bar (blue)
|
CA$13.26
|
|
|
104-630 |
| 45 |
900-177 |
Bolt, Flange M6x28 (Zn)
|
CA$2.15
|
|
|
900-177 |
| 46 |
102-350 |
Handle Connecting Bracket (Plastic)
|
CA$3.55
|
|
|
102-350 |
| 47 |
104-631 |
Complete Engine Assembly (274cc)
|
CA$295.69
|
|
|
104-631 |
| 48 |
900-074 |
Flat Washer 12x6x0.9mm (Red Paper)
|
CA$1.99
|
|
|
900-074 |
| 49 |
900-031 |
Spring Washer 5mm (BLK)
|
CA$1.99
|
|
|
900-031 |
| 50 |
101-385 |
Negative Battery Lead
|
CA$7.61
|
|
|
101-385 |
| 51 |
101-233 |
Positive Battery Lead (Red)
|
CA$6.92
|
|
|
101-233 |
| 52 |
900-027 |
Serrated Lock Washer 6mm (Zn)
|
CA$2.04
|
|
|
900-027 |
| 53 |
101-386 |
Frame Wire
|
CA$4.03
|
|
|
101-386 |
| 54 |
900-178 |
Bolt with flat washer, Flange M6x25 (Zn)
|
CA$2.44
|
|
|
900-178 |
| 55 |
101-387 |
Lead Acid Battery (12V, 9Ah)
|
CA$54.58
|
|
|
101-387 |
| 56 |
900-066 |
Stator Bolt, Flange M5x175 (BLK）
|
CA$3.29
|
|
|
900-066 |
| 57 |
900-147 |
Nylon Insert Lock Nut, Hex M6 (Zn)
|
CA$2.18
|
|
|
900-147 |
| 58 |
101-389 |
Battery Mounting Bar
|
CA$6.71
|
|
|
101-389 |
| 59 |
900-295 |
Hose Clamp 8.5mm
|
CA$2.35
|
|
|
900-295 |
| 60 |
101-999 |
Fuel Strainer
|
CA$3.65
|
|
|
101-999 |
| 61 |
102-273 |
Fuel Gauge
|
CA$7.46
|
|
|
102-273 |
|
103-378 |
Spark Arrester
|
CA$6.64
|
|
|
103-378 |
